W-R 50M56-743 GOODMAN DIRECT REPLACEMENT INTEGRATED FURNACE CONTROL HOT SURFACE IGNITION FOR MULTI-SPEED APPLICATIONS REPLACES GOODMAN 0130F00006(S) PCB00109 PCBBF109(S) PCBBF122(S) PCBBF132(S) PBCBF159(S) WHITE-RODGERS 50M56-289 & 290.
50M56-743
831893
78671054866
- 1-STAGE, MICROPROCESSOR BASED, INTEGRATED, MULTI-SPEED TYPE
- FURNACE, GAS VALVE, IGNITER, BLOWER, INDUCER AND AIR CLEANER APPLICATION
- -40 TO 176 DEG F TEMPERATURE RATING
- CURRENT RATING 0.45 AMP AT 30 VOLT AC
- IGNITER RELAY RATING 6 AMP AT 120 VOLT AC 50/60 HERTZ
- INDUCER RELAY RATING 2.2 AMP (FULL LOAD)/3.5 AMP (LOCKED ROTOR) AT 120 VOLT AC
- CIRCULATOR RELAY RATING 14.5 AMP (FULL LOAD)/25 AMP (LOCKED ROTOR) AT 120 VOLT AC
- HEAT DELAY TIME 30 SECOND (ON), 100/150 SECOND (OFF)
- COOL DELAY TIME 6 SECOND (ON), 45 SECOND (OFF)
- POST PURGE TIME 25 SECOND
- MOUNTING TYPE SURFACE MOUNT MULTIPOISE
- APPROVAL CSA (CANADA AND US)
- FLAME FAILURE RESPONSE TIME 2 SECOND
- FUEL TYPE NATURAL, MANUFACTURED, MIXED, LIQUEFIED PETROLEUM AND LIQUID PROPANE GAS AIR MIXTURE
- IGNITION SEQUENCE 2
- IGNITION SOURCE HOT SURFACE IGNITER
- IGNITION TRIAL TIME 4 SECOND
- POWER RATING 25 VOLT AC 50/60 HERTZ, 0.45 AMP
- PREPURGE TIME 30 SECOND
- VALVE RATING 1.5 AMP AT 25 VOLT AC 50/60 HERTZ
78671054866
