LIBERTY FL102M-2 1 HP, EFFLUENT PUMP, 1 PH, 208-230V, 25' CORD, 1.5IN / 2IN DISCH., MANUAL
FL102M-2
912761
67181213141
- SUBMERSIBLE, UNIQUE, 1-PIECE TYPE
- 11.8 INCH LENGTH OVERALL DIMENSIONS
- 25 FOOT POWER CORD LENGTH
- 208 TO 230 VOLT AC 60 HERTZ 1-PHASE 12 AMP (FULL LOAD)/28.5 AMP (LOCKED ROTOR) INPUT SUPPLY RATING
- 98 GPM AT 15 FOOT FLOW RATE
- CSA (CANADA AND US), UL APPLICABLE STANDARD
- DEWATERING PUMP APPLICATION
- 104 DEG F (CONTINUOUS LIQUID), 266 DEG F (STATOR), 248 DEG F (THERMAL OVERLOAD) TEMPERATURE RATING
- BUNA-N O-RING INCLUSIONS/FEATURES
- 1 HP POWER RATING
- THREADED OUTLET END CONNECTION
- 3 YEAR WARRANTY
- 3450 RPM SPEED RATING
- CLASS 25 CAST IRON HOUSING MATERIAL
- 17-4 PH STAINLESS STEEL SHAFT MATERIAL
- OIL FILLED MOTOR TYPE
- 90 FOOT DISCHARGE HEAD
- 1.5 INCH OR 2 INCH DISCHARGE SIZE
- CLASS 25 CAST IRON CASING MATERIAL
- CLASS 25 CAST IRON IMPELLER MATERIAL
- UNITIZED CARBON/CERAMIC SHAFT SEAL DETAILS
- 3-VANE IMPELLER DESIGN
- 3/4 INCH SOLID SIZE
- WIDE ANGLE FLOAT TYPE
- POWER CORD TYPE SJOOW
- FL100 MODEL
