LIBERTY 281 1/2HP CI SUB SUMP PUMP 1/2HP 115V 10ft CORD
281
802352
67181200281
- SUBMERSIBLE, UNIQUE, 1-PIECE TYPE
- 9.5 INCH WIDTH X 6.4 INCH DEPTH OVERALL DIMENSIONS
- 10 FOOT POWER CORD LENGTH
- 115 VOLT AC 60 HERTZ 1-PHASE 8 AMP (FULL LOAD)/23 AMP (LOCKED ROTOR) INPUT SUPPLY RATING
- 62 GPM AT 5 FOOT FLOW RATE
- UL, CSA (CANADA AND US), SSPMA APPLICABLE STANDARD
- LIQUID WASTE TRANSFER APPLICATION
- 140 DEG F (LIQUID), 266 DEG F (STATOR), 221 DEG F (THERMAL OVERLOAD) TEMPERATURE RATING
- BUNA-N O-RING INCLUSIONS/FEATURES
- 1/2 HP POWER RATING
- 3 YEAR WARRANTY
- 3450 RPM SPEED RATING
- POWDER COATED CLASS 25 CAST IRON HOUSING MATERIAL
- 25 FOOT/3 FOOT/50 FOOT POWER CORD LENGTH OPTIONS
- 300/400 STAINLESS STEEL SHAFT MATERIAL
- OIL-FILLED, PERMANENTLY LUBRICATED, PERMANENT SPLIT CAPACITOR MOTOR TYPE
- 37 FOOT DISCHARGE HEAD
- 1-1/2 INCH DISCHARGE SIZE
- ENGINEERED POLYMER IMPELLER MATERIAL
- UNITIZED CARBON/CERAMIC SHAFT SEAL DETAILS
- VORTEX IMPELLER DESIGN
- 3/4 INCH SOLID SIZE
- WIDE ANGLE/INTEGRAL FLOAT TYPE
- POWER CORD TYPE SJTW
- 280 MODEL
67181200281
PLBG
