AY 20GPM 1HP 230V 3 WIRE PL SUB PUMP
6634-232
908394
05356556122
- 9-STAGE TYPE
- 3-7/8 INCH DIAMETER X 28.53 INCH HEIGHT OVERALL DIMENSIONS
- 230 VOLT AC 60 HERTZ 1-PHASE INPUT SUPPLY RATING
- 20 GPM FLOW RATE
- NEC APPLICABLE STANDARD
- THERMOPLASTIC DISCHARGE HEAD/DIFFUSER/MOTOR BRACKET, INTERNAL, BUILT-IN CHECK VALVE, COUPLING, CABLE GUARD, 48 INCH LEAD INCLUSIONS/FEATURES
- 113 PSI PRESSURE RATING
- 1 HP POWER RATING
- FEMALE THREADED END CONNECTION
- STAINLESS STEEL SHAFT MATERIAL
- NEMA 3-WIRE BUILT-IN LIGHTNING PROTECTED MOTOR TYPE
- 261 FOOT DISCHARGE HEAD
- 1-1/4 INCH DISCHARGE SIZE
- STAINLESS STEEL CASING MATERIAL
- THERMOPLASTIC IMPELLER MATERIAL
- GLASS BEAD ACETAL, SMOOTH AND FLEXIBLE IMPELLER DESIGN
- THERMOPLASTIC SCREEN MATERIAL
- 22000, P MODEL
Stainless Steel
05356556122
WATR
